Dual Channel Bottle Aggregation Machine

Product Description

Technical Specification

• Compliance to : CE directives. 21 CFR part 11
• Machine dimensions : Length 1660 + 50 mm
• Width 1780 + 50 mm
• Height 1455 mm (100 + 50)
• Conveyor belt width : 105mm
• Working height : 700 mm (100 + 50)
• Weight : 200 kg (approx.)
• Belt speed : 10-35 m/min
• Running direction : Left to right
• Cabinet : Stainless steel with key locked space f controller and reject Tray
• Top cover : Transparent acrylic cover equipped safeguard switch to stop the machine opened during Production
• Rejection bin : Reject bin secured with key lock
• Rejection system : Pneumatic push out device available
• Mountings : Integrated mounting bracket for visior camera positioning
• Emergency operation : Switch on front panel. Hardware controlled emergency stop function

Connection / Input & Output

• External  connections : Main power, air pressure, upstream downstream machine control signals, LAN
• Electrical  connection: Voltage: 230 VAC (+ 10%)
• Frequency : 50/60 Hz
• Air pressure : 6 to 8 bar main supply
• Product position: Through sensor & encoder tracking
• Machine controller : PLC
• Input / Output : 36 Input & 24 Output

Vision System

• Camera lenses & resolution : 0.3 megapixcel image base vision system
• Inspection area : 40 (H) x 55(W) mm
• Light > Inbuilt multi color integrated light shielding
• Verification : 1D & 2D codes EAN13, Code128, PHARMACODE, Data Matrix, QR Code, PDF 417, CODE 39 & many more...
• Data matrix  standard: According to GS1 and ISO/IEC 16022

Production

• Reading position  : 360° +
• Bottle size (min. - max.)
• Diameter : 30-110mm
• Height : 70-225mm
• Throughput : Up to 200 bottles per minute
• Precise position: “Q” Management for bottle
• Display : 17’ Touch monitor
• Software : CSPL 2020 GUI to control all parameters and to comply 21 CFR Part 11
